Road frameset RIDLEY FENIX DISC - customisation
New in

Road frameset RIDLEY FENIX DISC - customisation

  • Fenix Disc is a high-performance endurance bike, but with a less considerable price. With this all-round road bike, you’ll be able to tackle anything: from steep climbs and long descends to challenging cobblestones.
2 442,00 €
incl. VAT / piece
Lowest price in 30 days before discount: / piece
Regular price: / piece
Before we process the order with this product, the prepayment in the amount of 611,00 €. may be required. Detailed information will be provided in the order summary, before its placement.
Availaible on request
Availaible on request
14 days for free returns
This product is not available in a stationary store
Safe shopping

*rzeczywista specyfikacja produktu może różnić się od przedstawionej na zdjęciu. Prosimy o zapoznanie się z dokładną specyfikacją poniżej.

Fenix Disc is a high-performance endurance bike, but with a less considerable price. Meet the Fenix Disc: the more affordable sibling of our Fenix SLiC. With this all-round road bike, you’ll be able to tackle anything: from steep climbs and long descends to challenging cobblestones. The Fenix Disc has similar riding quality and characteristics to the Fenix SLiC. The frame has the same geometry and features the same diamond shaped down tube which provides extra stiffness and durability. Using different carbon fiber technology and due to modified carbon lay-up, the Fenix Disc frame is only 120 grams heavier than our Fenix SLiC frame while maintaining the stiffness and ride comfort of the top level Fenix SLiC. It offers precise handling and immediately reacts to every pedal stroke, while giving you the feeling that you’re floating above the road surface.

  • wide BB86 bottom bracket, oversized head tube and the diamond-shaped down tube means every pedal stroke is converted into speed
  • curved top tube, the 27.2mm seat tube and the fine rear stays provide a high level of comfort
  • availaible to use tires up to 28mm
  • integrated cables and an aerodynamic handlebar for optimal performance, clean look, and minimal maintenance
  • compatible with electronic and mechanical shifting
  • compatible with flatmount disc brakes
  • availaible at sizes XS-XL
XS S M L XL Geometry-Road
754 781 812 839 869
B - SEAT TUBE, CENTER-TOP 464 492 522 549 579
C - TOP TUBE, HORIZONTAL 525 545 565 587 603
D - HEAD TUBE LENGTH 117 140 164 194 218
E - SEAT TUBE ANGLE 74,0 73,5 73,0 72,5 72,5
F - HEAD TUBE ANGLE 72,0 73,0 73,5 73,5 74,0
G - CHAINSTAY LENGTH 410 410 410 413 413
H - BB DROP 68 66 66 63 63
I - WHEELBASE 975 982 992 1012 1022
J - STANDOVER HEIGHT 785 809 840 870 898
S - STACK 517 541 565 591 615
R - REACH 377 385 392 401 409
Fenix Disc, 24T HM UD Carbon, Diamond Shape, F-Steerer, TA 12x142mm
Frame material
Fenix Disc, 30T-24T HM UD Carbon, Straight Blade, F-Steerer, TA 12x100mm
customisation level 1
FSA 1 1/8 x 1 1/4 integrated
Wheel axles
F TA12x100
R TA12x142
Saddle clamp
Front derailleur
Braze-On type
standard Press-Fit BB86
F140/160mm FlatMount
R140/160mm FlatMount
RIDLEY [5 years]

All RIDLEY frames are warranted by Producer against manufacturing defects in material and/or workmanship for 5 years of the original owner if the frame is purchased from an Authorized Ridley Dealer who perform warranty checkup before sale what is confirmed with a proper receipt/invoice. Frame must be registered within one month after purchase at at Producer website
In case of complete bicycles components are warranted separate by specific producer (usually for 2 years).

Future service, maintenance and repairs should be performed according to your knowledge and skills by yourself or by an Authorized Ridley Dealer, or in case of lack of a one in you area at preferred professional bicycle workshop.

Please contact us if any further instructions are needed.

Do you need help? Do you have any questions?Ask a question and we'll respond promptly, publishing the most interesting questions and answers for others.
Ask a question
If this description is not sufficient, please send us a question to this product. We will reply as soon as possible. Data is processed in accordance with the privacy policy. By submitting data, you accept privacy policy provisions.
Write your opinion
Your opinion:
Add your own product photo:
SizeMin. leg lenghtMax. leg lenghtHeight
XS79 cm83 cm162 - 170 cm
S83 cm87 cm170 - 178 cm
M87 cm91 cm178 - 186 cm
L91 cm95 cm186 - 194 cm
XL95 cm99 cm> 194 cm

Instrukcja mierzenia

Aby dokładnie ustalić rozmiar niezbędny do zamówienia roweru lub ramy szosowej RIDLEY należy zmierzyć się i porównać wymiary swojego ciała z wymiarami podanymi w tabeli.

Pomiary wykonujemy taśmą centymetrową stojąc w pozycji wyprostowanej i swobodnie oddychając, najlepiej w stroju kolarskim lub bieliźnie.

  1. Długość nogi - mierzymy w linii prostej od kroku (górna płaszczyzna poziomicy lub innego przedmiotu) do podłoża stojąc bez obuwia ze stopami ustawionymi ok. 20 cm od siebie.
  2. Wzrost - mierzymy w linii prostej od wierzchołka głowy do podłoża stojąc bez obuwia, ze złączonymi stopami.
