Road bicycle RIDLEY HELIUM SLX DISC - Super Record EPS 2x12s - configurator

  • The Helium SLX Disc frame is our ultra-gourmet bike. It’s simply at the highest level when it comes to stiffness to weight ratio. We’ve designed it to be as light as possible to tackle the longest, steepest climbs.
11 814,00 €
incl. VAT / piece
Lowest price in 30 days before discount: / piece
Regular price: / piece
Before we process the order with this product, the prepayment in the amount of 2 953,00 €. may be required. Detailed information will be provided in the order summary, before its placement.
Availaible on request
Availaible on request
14 days for free returns
This product is not available in a stationary store
Safe shopping
Size
Color
Wheelset
Tires
Cockpit
Saddle

*rzeczywista specyfikacja produktu może różnić się od przedstawionej na zdjęciu. Prosimy o zapoznanie się z dokładną specyfikacją poniżej.

The Helium SLX Disc frame is our ultra-gourmet bike. It’s simply at the highest level when it comes to stiffness to weight ratio. We’ve designed it to be as light as possible to tackle the longest, steepest climbs. Yet it is stiff and durable enough to expertly handle the likes of Thomas De Gendt’s one-minute at 500W early breakaway effort. Hence, weight as well as performance is built into this frame as it must satisfy the most demanding of our pro cyclists. The Helium SLX Disc is not only built for the pros, but is designed for anyone who wants to pull everything out of their bike. It’ll help you to be fast on the climbs to grab those Strava KOM’s, fly on the flats and rolling terrain, and sprint like a pro. It’s also comfy enough to keep you motivated to ride long distances to tackle Gran Fondos. By using disc brakes you don’t only have a bike that expertly helps you count altimeters, but provides you with full control in the descent as well.

  • use of extremely high modulus aerospace carbon in combination with nano resin to save weight without reducing stiffness
  • oversized round tube shape offer the best stiffness to weight ratio
  • use of 12 mm thru-axle increased the frame’s stiffness
  • specially designed oversized PF30 bottom bracket offers a very high level of stiffness for maximal power transfer
  • tapered 1 1/8 - 1 1/4 head tube with angular contact bearings
  • flex seat stays provide comfort without sacrificing stiffness
  • straight blade fork adds to that sublime handling taking hairpin bends
  • aerodynamically optimized by using F-Steerer technology - every cable can be integrated to create a clean cockpit
  • compatibile with flatmount discbrakes
  • compatible with electronic and mechanical shifting
HELIUM SLX DISC
XXS XS S M L XL Geometry-Road
A - MAX. SADDLE HEIGHT
740 770 800 830 860 890
B - SEAT TUBE, CENTER-TOP 450 480 510 540 570 600
C - TOP TUBE, HORIZONTAL 515 525 545 565 585 600
D - HEAD TUBE LENGTH 110 130 145 175 205 230
E - SEAT TUBE ANGLE 75,0 74,0 73,5 73,0 72,5 72,5
F - HEAD TUBE ANGLE 71,8 72,0 73,0 73,5 73,5 74,0
G - CHAINSTAY LENGTH 405 405 405
405 408 408
H - BB DROP 68 68 66 66 63 63
I - WHEELBASE 970 970 977
987
1005 1014
J - STANDOVER HEIGHT 721 755 775 804 834 861
S - STACK 507 527 542 573 599 624
R - REACH 374 379 384 390 396 403
Brand
Series
BICYCLE SPECIFICATION
Frame
Helium SLX Disc, 60T-40T-30T HM UD Carbon, F-Steerer, TA 12x142mm
Frame material
carbon
Frame weight (at size M)
825 g
Fork
Helium SLX Disc, 60T-40T-30T HM UD Carbon, F-Steerer, TA 12x100mm
Headset
FSA 1 1/8 x 1 1/4 integrated
Dual-Control levers
Campagnolo Super Record EPS 2x12s
Front derailleur
Campagnolo Super Record EPS 2s
Rear derailleur
Campagnolo Super Record EPS 12s
Crankset
Campagnolo Super Record Carbon 52/36
BB
Campagnolo PF30
Cassette
Campagnolo Super Record 12s 12-32
Chain
Campagnolo Super Record 12s
Brakes
Campagnolo Super Record Hydraulic Disc, FlatMount
Bar tape
Forza
Seatpost
Forza Cirrus 27.2mm Carbon-Alu/24mm offset
Saddle clamp
Forza
To download
RIDLEY [5 years]

All RIDLEY frames are warranted by Producer against manufacturing defects in material and/or workmanship for 5 years of the original owner if the frame is purchased from an Authorized Ridley Dealer who perform warranty checkup before sale what is confirmed with a proper receipt/invoice. Frame must be registered within one month after purchase at at Producer website www.ridley-bikes.com/register-ridley
In case of complete bicycles components are warranted separate by specific producer (usually for 2 years).

Future service, maintenance and repairs should be performed according to your knowledge and skills by yourself or by an Authorized Ridley Dealer, or in case of lack of a one in you area at preferred professional bicycle workshop.

Please contact us if any further instructions are needed.
