Gravel frameset RIDLEY KANZO FAST - color KAF-02As (Battleship Grey-Orange-Dove Grey)
New in

Gravel frameset RIDLEY KANZO FAST - color KAF-02As (Battleship Grey-Orange-Dove Grey)

  • The Kanzo Fast gravel bike is lightning fast on any terrain. No gravel bike is as responsive. It's perfect, aerodynamic gravel bike to win gravel races. "It's The Fastest Way To Escape!
3 604,00 €
incl. VAT / piece
Lowest price in 30 days before discount: / piece
Regular price: / piece
Before we process the order with this product, the prepayment in the amount of 901,00 €. may be required. Detailed information will be provided in the order summary, before its placement.
Availaible on request
Availaible on request
14 days for free returns
This product is not available in a stationary store
Safe shopping
Size
Color
Cockpit
Seatpost
Mudguards

*rzeczywista specyfikacja produktu może różnić się od przedstawionej na zdjęciu. Prosimy o zapoznanie się z dokładną specyfikacją poniżej.

The Kanzo Fast gravel bike is lightning fast on any terrain. It's effective power transfer helps you convert every single watt into maximum speed. No gravel bike is as responsive. It's also expert at cutting through wind while keeping you comfortable to ensure that you can confidently go the distance. Ridley engineers spent hours in the wind tunnel and on gravel roads for further development and testing. What we created in the end was the perfect, aerodynamic gravel bike to win gravel races. "It's The Fastest Way To Escape!

  • F-Steerer ingeniously allows for fully internal cabling
  • F-Tubing is our droplet-shaped tubing which significantly minimizes wind drag
  • F-Wings reduces drag by drawing turbulent air away from spokes
  • compatible with electronic and mechanical 1x shifting
  • maximum tire clearance of 700x42 and fender mounts on frame and fork
  • the flexzones in the rearstays offer extra comfort by filtering the vibrations from all the different roadsurfaces you will ride
  • all cables run full internally through the frame which avoids mud and water to ruin your shifting performance
  • 12mm TA in frame and fork
  • compatibile with flatmount disc brakes
KANZO FAST
XS S M L XL Geometry-Road
A - MAX. SADDLE HEIGHT
760 785 810 835 860
B - SEAT TUBE, CENTER-TOP 470 495 520 545 570
C - TOP TUBE, HORIZONTAL 522 547 565 587 601
D - HEAD TUBE LENGTH 115 144 168 197 221
E - SEAT TUBE ANGLE 74,5 73,5 73,0 72,5 73,0
F - HEAD TUBE ANGLE 71,0 71,0 71,5 71,5 72,0
G - CHAINSTAY LENGTH 425 425 425 425 425
H - BB DROP 74 72 72 70 70
I - WHEELBASE 1001 1017 1026 1044 1053
J - STANDOVER HEIGHT 768 794 819 844 869
S - STACK 537 563 587 613 638
R - REACH 372 380 385 393 400



Brand
FRAMESET SPECIFICATIONS (SET INCLUDES):
Frame
Kanzo Fast, 30T HM/HR UD Carbon, F-Tubing, TA 12x142mm
Frame material
carbon
Frame weight (at size M)
1190 g
Fork
Kanzo Fast, 30T HM/HR UD Carbon, F-Steerer, F-Wings, TA 12x100mm
Headset
FSA 1 1/8 x 1 1/4 integrated
Wheel axles
F TA12x100
R TA12x142
Saddle clamp
integrated
COMPATIBILITY:
BB
standard Press-Fit BB86
Brakes
F140/160mm FlatMount
R140/160mm FlatMount
To download
RIDLEY [5 years]

All RIDLEY frames are warranted by Producer against manufacturing defects in material and/or workmanship for 5 years of the original owner if the frame is purchased from an Authorized Ridley Dealer who perform warranty checkup before sale what is confirmed with a proper receipt/invoice. Frame must be registered within one month after purchase at at Producer website www.ridley-bikes.com/register-ridley
In case of complete bicycles components are warranted separate by specific producer (usually for 2 years).

Future service, maintenance and repairs should be performed according to your knowledge and skills by yourself or by an Authorized Ridley Dealer, or in case of lack of a one in you area at preferred professional bicycle workshop.
